A defect register, not a heat map.
Raw thermal imagery is the input, not the deliverable. Every anomaly is classified, scoped on the RGB, and assigned a severity by an experienced building envelope specialist.
Radiometric capture
Two-camera payload — radiometric IR plus 20 MP RGB on the same pass. Calibrated against blackbody reference each flight.
Defect classification
Moisture intrusion, missing insulation, air leakage, and detached membrane — each typed and severity-rated.
IR + RGB composite
Every defect ships with the IR scan and the RGB photo of the same patch — context, not just color.
Routable register
Defects export to your CMMS as work orders. Scope, location, and evidence travel together.
Roof + façade in one pass
Same flight covers both surfaces. Façade is captured at ~30° pitch for full envelope coverage.
Envelope specialist sign-off
Every report is reviewed and signed by an experienced building envelope specialist.
One report, every defect.
A single PDF and a single CSV — not a folder of raw IR scans.
What's in the contract before anyone flies.
- Resolution
- 640 × 512
- Spectral
- 7.5 – 13.5 µm
- Accuracy
- ±2°C
- NETD
- < 50 mK
- Window
- 1–3 hr post-sunset
- Δ inside/out
- ≥ 18°F
- Wind cap
- < 15 mph
- Pitch
- Top + 30° oblique
- Pilot
- Adv RPAS
- Analyst
- Building Envelope
- Insurance
- $2M GL
- Airspace
- NAV CANADA
- Turnaround
- < 5 business days
- Format
- PDF · CSV · API
- Retention
- 7 years
- Re-fly
- Free if Δ < 12°F
Fixed-fee. Quoted in advance. No hourly surprises.
Every site is different — your quote depends on size, complexity, and access. These are the starting points so you can budget before the scope call.
- On-site flight (2–4 hrs)
- Radiometric report (≤25 anomalies)
- GPS-tagged anomaly map
- 1 round of analyst Q&A
- Everything in Single Building
- Volume pricing across portfolio
- Consolidated capex prioritisation report
- Dedicated specialist contact
- 48-hour expedited delivery
- Closing-timeline coordination
- Comprehensive due-diligence report formatted for lender and underwriter review · partner-P.Eng. sign-off available as add-on
- Live walk-through with acquisition team
All prices in CAD, exclusive of GST. Travel beyond 100 km of YYC may incur a per-diem.
